"Joyreap self-service payment terminal is a self-service payment device that integrates multiple payment methods and printing functions. It aims to provide users with a fast and convenient payment experience, while also helping merchants improve operational efficiency."
- Item NO:JRK06
- Color:White
- Min Order:1
- Cpu:Intel J4125/I3/I5/I7 (Optional)
- Memory:DDR3 4G/8G/16G(optional)
- Hard Disk:mSATA SSD 64GB/128G/256G/1TB(optional)
- Screen :15.6/21.5/23.6/27/32 inch capacitive touch screen
DESCRIPTION：
- CPU:Intel® J4125/J1900/I3/I5/I7 & RK3566/RK3568/RK3288...
- Memory DDR:4GB/8GB/16GB(optional)
- Hard Drive:32GB /64GB/128GB to 256 GB, hard disc 320-500GB
- Operation System:Wins 7/Wins 8/Windows 10 & Android11.0
- Display:15.6、21.5、23.6 inch capacitive 10 point touch screen
- Color: White
- Dimension( Wx H x D ): Machine- 490*460*850mm; Bracket- 260*220*870mm
- Weight: Machine- 22KG; Bracket-8.5KG
- Built in thermal printer
- Built in QR Scanner
- Built in WIFI and Speaker
- Optional: Built in NFC, LED light strip...Support customization
Product configuration:
|
Model : JRK06 |
|
|
Optional Color |
White |
|
Material |
Aluminum Alloy + ABS Plastic |
|
CPU |
I3 Quad-core 2.0 GHz-2.7 GHz (default) ; J6412/I3/ I5/ I7 Can Choose |
|
Memory Support |
DDRIII 1066/1333*1 4GB(default); 8GB Can Choose |
|
Hard Driver |
SSD 64G (default); 128GB/256GB/512GB/1TB Can Choose |
|
Home screen LED panel Size |
27Inch LED monitor, Aspect ratio 16:9, resolution 1920 * 1280 |
| Touch Screen | True flat 10 Point Capacitive Touch Screen |
|
Brightness |
250cd/m2 |
|
Touch Screen |
10-point capacitive touch screen |
|
Default Built in |
58mm printer/QR code/WIFI built-in |
|
I/O port |
1* power button DC in *1 |
|
Serial*1 DB9 male |
|
|
VGA(15Pin D-sub)*1 |
|
|
LAN:RJ-45*1 USB(2.0)*4 USB(3.0)*2 |
|
|
Audio out*1 MIC IN*1 HDMI*1 |
|
|
Operating temperature |
0℃ to 40℃ |
|
Storage temperature |
-20℃to 60℃ |
|
Power Consumption |
35W(max) |
|
Compliance |
FCC Class A/CE Mark/LVD/CCC |
|
Packing dimension/ Weight |
490*460*850mm / 22.0 Kgs ; 260*220*870cm/8.5Kgs |
|
Operating System |
win10/11 linux Android 11/12/13 |
|
Power adapter |
110-240V/50-60HZ AC power, Input DC12/5A out put |
|
Other part options |
Cash drawer/Barcode Scanner/VFD display/Printer |
Feature:
1. Fast and convenient self-service payment experience: The intuitive touch screen interface allows users to quickly complete the payment process without waiting in line, saving valuable time
2. 7*24 hours uninterrupted service around the clock: Whether it is weekdays or holidays, the equipment is on standby to serve users at any time, improving customer convenience and satisfaction
3. One-stop payment with multiple payment methods: Supports multiple payment methods such as cash, bank cards, mobile payments, etc. to meet the payment habits and needs of different users
4. Integrated printing function, providing electronic bills: Supports instant printing of electronic invoices or receipts, which is convenient for users to save transaction records
5. Intelligent management, improve operational efficiency: Support remote monitoring and fault alarm, optimize equipment deployment and operation and maintenance strategies through data analysis
In general, Joyreap self-service payment terminal has many advantages such as convenient use, all-weather service, support for multiple payment methods, integrated printing function, and intelligent management. It can provide users with a fast and efficient self-service payment experience, and also improve the operational efficiency of merchants. These features are all selling points worth emphasizing.
